70w DALI-2 DT6 Dimmable Driver
- BAG’s Product Code – 10116488/10218128
- Description – LEDC BAG NCD140-70LS/USG1/D2/109/STD
- Max Output Wattage – 70W
- Output VDC – 40 – 250
- Output Current – 120mA – 400 mA
- Pf – 0.98
- Efficiency – 0.9
Download Datasheet
- “Dimming range 3% to 100%
- Ouptput Current adjustment 120-400mA using Digital Programming or Rset(Default Current 120mA)
- Output Current accuracy – 5%
- Dimming Interfacte – DALI Device Type 6 (DT6)
- Push Dim
- THD<10%
- Flicker Free Operation
- Overvoltage Protection upto 350VAC
- Short Circuit, Over Temp & Open circuit Protection
- Safety Standards – EN61347-1, EN61347-2-13
- EMC Emission : En55015, EN61000-3-2, EN61000-3-3
- EMC Immunity – En61547, EN61000-4-2,3,4,5,6,8,11
- Non isolated Metal Casing
- Dimension:280x30x21mm (L*W*H)
- Warranty : upto 5 Year warranty
- Applications : Linear Lights & Panel Lights “
